Lever Valves 1121A2002





  • Lever Valves
  • Toggle Lever Valves
  • Hand Lever Valves

Need Help? No Problem!

Technical & Customer Service

+44 (0)1254 872277

Need Help? No Problem!

Technical & Customer Service

+44 (0)1254 872277


Product Information

Valve Type Directional Control
Series 11
Application General
Actuation Manual Toggle Lever
Function 2/2
Default Position Normally Open
Return Spring
Thread Type NPT
Inlet Pipe Size 1/4"
Outlet Pipe Size 1/4"
Construction Poppet
Mounting Inline
Avg Cv 0.5
Ambient Temperature -10 to 175 F (-23 to 80 C)
Media Temperature -10 to 175 F (-23 to 80 C)
Fluid Media Filtered Air
Operating Pressure 5 to 150 psig (0.3 to 10 bar)
Length 2.12 in (54 mm)
Width 2.76 in (70 mm)
Height 5.92 in (150 mm)
Weight 1.0 lb (0.5 kg)
Valve Body Material Cast Aluminum
Lever Position Vertical
