Flow Controls 1968A1108
- Low profile, high capacity & right angle series available
- Available with NPT & BSPP port threads
- Low profile series includes slot & knob adjustment options
- High capacity series includes inline & offset orientation options
- Right angle series includes slot & knob adjustment options
Product Information
Valve Type | Flow Control Valve |
Series | 19 |
Application | General |
Actuation | Pneumatic |
Function | 2/2 |
Thread Type | NPT |
Inlet Pipe Size | 1/8" |
Outlet Pipe Size | 1/8" |
Construction | Poppet |
Mounting | Inline |
Avg Cv | 0.3 |
Ambient Temperature | 40 to 175 F (4 to 80 C) |
Media Temperature | 40 to 175 F (4 to 80 C) |
Fluid Media | Filtered Air |
Operating Pressure | 5 to 150 psig (0.3 to 10 bar) |
Length | 0.63 in (16 mm) |
Width | 1.0 in (25 mm) |
Height | 1.4 in (36 mm) |
Weight | 0.06 lb (0.03 kg) |
Valve Body Material | Cast Aluminum |
Adjustment | Slot |
Profile | Right Angle |
